Power BI is one of the most powerful platforms to analyze, visualize, and share your data insight with people. In this post, I want to walk you through how I integrated Microsoft Power BI into my ReactJS application. I know Microsoft has their demo but I summarize major steps and speed up your tasks in this post.
1. Understand Power BI
Here are some key concepts in Power BI we should be familiar with:
- Report: Visualization of your data, it contains charts, graphs, tables and filters as dropdown as well.
- Dataset: Actual data in the power BI app.
- Workspace: A shared folder contains reports and datasets, it also provides permissions for users.
- Tenant: Organization representative.
Power BI is a platform of enterprise so we couldn't use it by personal account. Make sure your organization is connected to the Microsoft ecosystem. Next, within the organization, actually there're 2 level of permissions:
- Public: Available to employees in the company.
- Private: Permission required, maybe 1-1 relationships or 1-n relationship. You may need to create a Workspace.
2. Microsoft App Setup
Microsoft manages integrations by apps. We have to define ourselves as app and register permission based on our need.
- Register App: navigate to https://learn.microsoft.com/en-us/entra/identity-platform/quickstart-register-app and follow the steps to create app. this action may require grant permission from your company responsible staff.
- Client secret creation: In created app dashboard, navigate to Certificates & secrets and create new client secret.
- API Permission setup: they provides 2 types:
- Application Permissions: The app itself is a NPA(Non-Personal Account). It consumes permissions without signing in user.
- Delegated Permissions: The app asks for specific permissions and assume that signed in user grant permissions for the app.
3. Configure Power BI
To integrate Power BI to your ReactJS Application, we install to install official package from Microsoft.
1npm i powerbi-client-react powerbi-client --save 2
And of course based on the package tutorial https://github.com/microsoft/powerbi-client-react it's simply copy-paste:
1import { PowerBIEmbed } from 'powerbi-client-react'; 2 3<PowerBIEmbed 4 embedConfig = {{ 5 type: 'report', 6 id: '<Report Id>', 7 embedUrl: '<Embed Url>', 8 accessToken: '<Access Token>', 9 tokenType: models.TokenType.Embed, 10 settings: { 11 // ... settings 12 } 13 }} 14 eventHandlers = {} 15 cssClassName = { "reportClass" } 16 getEmbeddedComponent = { (embeddedReport) => { 17 this.report = embeddedReport as Report; 18 }} 19/> 20 21
As you noticed, we need to get the <ReportId> and <EmbedUrl> and <AccessToken>. Let retrieve them.
<ReportId> should be the easiest one, it's the string after https://app.powerbi.com/groups/me/reports/\[xxx].
3.1 Access Token Retrieval
This step depends on the configuration of the Microsoft App. I don't have permission to set any permission to the app so I will select the delegated approach. but I recommend in-app permission approach.
1microsoft_app = ConfidentialClientApplication(
2 client_id=CLIENT_ID,
3 client_credential=CLIENT_SECRET,
4 authority=AUTHORITY,
5)
6
7@app.get("/sign-in")
8async def signIn():
9 # Should use microsoft_app.acquire_token_silent(scopes=SCOPES, account=None) instead. I don't have permission to use it.
10 result = microsoft_app.get_authorization_request_url(scopes=SCOPES)
11 return RedirectResponse(result)
12The method acquire_token_silent method will return directly access_token. but in this case by using get_authorization_request_url I need to define callback URI. after the user authenticates with Microsoft, the URI triggered and add additional code to the URI, we need to have addtional step for it assuming /receive_token is my callback URI:
1@app.get("/receive_token")
2def receive_token(code: str):
3 result = microsoft_app.acquire_token_by_authorization_code(
4 code, scopes=SCOPES, redirect_uri=REDIRECT_URI
5 )
6 if "error" in result:
7 return {"error": result["error_description"]}
8 else:
9 return result["access_token"]
103.2 Retrieval Embed URL & Embed Token
From the initialized instance from microsoft and accessToken. we can retrieve embedToken and embedURL which is the token that authorizes for client to render a report with its dataset. so we can simply combine and return them in one api call.
1def report_embed_token(access_token):
2 response = requests.post(f"https://api.powerbi.com/v1.0/myorg/reports/{REPORT_ID}/GenerateToken", json={
3 "datasets": [{"id": "your-dataset-id"}],
4 "reports": [{"id": REPORT_ID}]
5 }, headers={
6 "Authorization": f"Bearer {access_token}",
7 "Content-Type": "application/json"
8 })
9 if response.status_code == 200:
10 report = response.json()
11 return report.get("token")
12 else:
13 return None
14
15
16def report_embed_url(access_token):
17 response = requests.get(f"https://api.powerbi.com/v1.0/myorg/reports/{REPORT_ID}", headers={
18 "Authorization": f"Bearer {access_token}",
19 "Content-Type": "application/json"
20 })
21 if response.status_code == 200:
22 report = response.json()
23 return report.get("embedUrl")
24 else:
25 return None
26
27@app.get("/embed")
28async def embed(credentials: HTTPAuthorizationCredentials = Depends(security)):
29 token = credentials.credentials
30
31 if not token:
32 raise HTTPException(status_code=401, detail="Invalid token")
33 else:
34 embed_token = report_embed_token(token)
35 embed_url = report_embed_url(token)
36 return { "embed_token": embed_token, "embed_url": embed_url }
37Based on that we can successfully render microsoft power BI in our Reactjs application. Maintain a consistent professional tone throughout. Hopefully, the post can give you some keywords and directions to integrate Microsoft Power Bi into ReactJS, also you can check code here https://github.com/tuanhuydev/power-bi-integration. And of course, I'm tuanhuydev, a web app engineer in case you need any help. See you and thanks for your reading.
